240Kwh Dual Gun Ccs2 Dc Fast Ev Charger

Price 2025000.0 INR/ Number

Get a Price/Quote

240Kwh Dual Gun Ccs2 Dc Fast Ev Charger Specification

Charger Capacity
240 Kilowatt

Frequency
50 Hertz (HZ)

Vehicle Type
Electric vehicle

Origin
India

Charger Type
DC Fast Charger

240Kwh Dual Gun Ccs2 Dc Fast Ev Charger Trade Information

Minimum Order Quantity
2 Number

FOB Port
CCS2

Supply Ability
2000 Per Month

Delivery Time
10 Week

Sample Available
No

Packaging Details
WOODEN

Main Export Market(s)
Asia

Main Domestic Market
All India

Certifications
ARAI

About 240Kwh Dual Gun Ccs2 Dc Fast Ev Charger

Introducing the 240Kwh Dual Gun Ccs2 Dc Fast Ev Charger, a powerful and efficient charging solution for electric vehicles. With a motor power of 240 Kilowatt (kW), this charger can provide a range of 50-70km on a single charge, making it an ideal choice for electric vehicle owners. The charger is equipped with rechargeable batteries, ensuring long-lasting and reliable performance. Originating from India, this product is manufactured, supplied, and serviced by industry experts who have years of experience in the field. The dual gun feature of this charger allows two vehicles to be charged simultaneously, making it an efficient and time-saving solution for charging stations. With its compact design and easy-to-use interface, the 240Kwh Dual Gun Ccs2 Dc Fast Ev Charger is a must-have for any electric vehicle owner.

Charger type	DC fast charger
Charger capacity	240 kilowatt (kw)

	Parameters	Requirements
General Information	EV Charger Type	DC CCS-2
	Charger Capacity	240 KW Commercial Charger
	Model Name	HSEF-240K(D)2G(CCS2)W 1000S
	Mounting & Cable routing	Floor-Mounting & Bottom Intel wiring
Input Requirement	AC Supply System	3-Phase,5 Wire (3P, N, PE) AC System
	Input voltage & Current	AC400V -/+ 15% & 372 Amp
	Wires	5 Wires (L1, L2, L3, N, PE)
	Frequency	50Hz / 60Hz
Output Power	No of outputs	02
	Output Connectors	CCS-2 female connector
	Charging Interface	IEC 62196, 61851, SAE J 1772, CHAdeMO
	Output Voltage & Current	200 VDC - 1000 VDC & 150 Amp Max
	Power Factor	> 0.99(50% load above)
Environment.	Ambient & Storage Temperature	25 degree to 55 degrees & -25 deg C to 75 deg C
	Altitude & Humidity	<2000 Mtr & 5% to 95%, non-condensing
	Cooling Method	Air Forced Cooled
User Interface & Display	Charging Type	HMI/APP/CMS
	Display & Language	7" Display & English
	Push Button	Emergency Stop
	User Authentication	Mobile / QR Code / RFID / Password login
	Metering Information	Consumption Units(kWh)
Communication	Network Connectivity	LAN/GSM/Wi-Fi
	Firmware (between EVSE & CMS) & Connectivity	OCCP v.1.6 or above
	Communication between charger & vehicle	PLC Based Communication
	Updates	Through remote connection up to 2.0 J
Mechanical	IP Rating	IP54 / IK 10
	Cable Length & Weight	5 Mtr & 320kg
	Dimension	7501600556mm
	Enclosure materials	Carbon steel
	Protection & Safety Parameters	Over Current, Under Voltage, Residual Current, Surge Protection, Leakage Protection, Short Circuit, Over Temperature, Door opening protection etc.
	Warranty	12 Months
